Shipping & Freight Calculation Tools

Our list of tools are resources for shipping & freight calculations

Conversion Tools

Length Multiply by
Inches to Centimetres 2.54
Centimetres to Inches 0.39
Inches to Millimetres 25.40
Millimetres to Inches 0.04
Feet to Metres 0.31
Metres to Feet 3.28
Yards to Metres 0.91
Metres to Yards 1.09
Miles to Kilometres 1.61
Kilometres to Miles 0.62

Volumetric Conversion

Box
cm/kg Inches/Pounds
cm
cm
cm
kg

Air Freight

ID CODE AMP
U.S. Domestic Code -
Aircraft Types & Main or Lower Decks All 747's &767 &AB3, Lower Deck
Rate Class 2BG
Internal Volume 11.4 m3 (403 cu ft)
Limiting Internal Dimensions 229 x 302 x 152 cm, (90 x 119 x 60 in)
Maximum Gross Weight 4626 kg (10200 lb)
Tare Weight 266 kg (587 lb)
ID CODE AAU
U.S. Domestic Code LD-29
Aircraft Types & Main or Lower Decks All 747's, Lower Deck
Rate Class 5W
Internal Volume 14.5 m3 (511 cu ft)
Limiting Internal Dimensions 208 x 302 x 152 cm, (82 x 119 x 60 in)
Maximum Gross Weight 4626 kg (10200 lb)
Tare Weight 260 kg (573 lb)
ID CODE AKN, AVN, AVA, AVE, AKE
U.S. Domestic Code LD-3
Aircraft Types & Main or Lower Decks All 747's & 767 &AB3, Lower Deck
Rate Class 8
Internal Volume 4.3 m3 (153 cu ft)
Limiting Internal Dimensions 140 x 147 x 152 cm, (55 x 58 x 60 in)
Maximum Gross Weight 1587 kg (3500 lb)
Tare Weight -
ID CODE AVC, AVJ, AKC
U.S. Domestic Code LD-1
Aircraft Types & Main or Lower Decks All 747's & 767, Lower Deck
Rate Class 8
Internal Volume 4.84 m3 (171 cu ft)
Limiting Internal Dimensions 140 x 147 x 152 cm, (55 x 58 x 60 in)
Maximum Gross Weight 1587 kg (3500 lb)
Tare Weight -
ID CODE DLF, DQF
U.S. Domestic Code LD-8
Aircraft Types & Main or Lower Decks 767, Lower Deck
Rate Class 6A
Internal Volume 7.2 m3 (253 cu ft)
Limiting Internal Dimensions 140 x 233 x 152 cm, (55 x 92 x 60 in)
Maximum Gross Weight 2449 kg (5400 lb)
Tare Weight 128 kg (282 lb)
ID CODE P1P, PAG, PAP, PAJ (Small)
U.S. Domestic Code LD-7
Aircraft Types & Main or Lower Decks All 747's &767 &AB3, Lower Deck
Rate Class 2C
Internal Volume -
Limiting Internal Dimensions -
Maximum Gross Weight 4626 kg (10200 lb)
Tare Weight 110 kg (242 lb)
ID CODE P1P, PAG, PAP, PAJ (Large)
U.S. Domestic Code M-1
Aircraft Types & Main or Lower Decks 747 Freighter, Main Deck
Rate Class 2C
Internal Volume -
Limiting Internal Dimensions -
Maximum Gross Weight 6800 kg (15000 lb)
Tare Weight 110 kg (242 lb)
ID CODE P6P, PMC
U.S. Domestic Code M-1
Aircraft Types & Main or Lower Decks 747 Freighter, Main Deck
Rate Class 2H
Internal Volume -
Limiting Internal Dimensions -
Maximum Gross Weight 4626 kg (10200 lb)
Tare Weight 110 kg (242 lb)
ID CODE RAP (Refrigerated Container)
U.S. Domestic Code -
Aircraft Types & Main or Lower Decks All 747's &767 &AB3, Lower Deck
Rate Class 5
Internal Volume 9.6 m3 (339 cu ft)
Limiting Internal Dimensions 208 x 305 x 147 cm, (82 x 119 x 60 in)
Maximum Gross Weight 4626 kg (10200 lb)
Tare Weight 400 kg (880 lb)
ID CODE RAP (Refrigerated Container)
U.S. Domestic Code -
Aircraft Types & Main or Lower Decks All 747's &767 &AB3, Lower Deck
Rate Class 5
Internal Volume 9.6 m3 (339 cu ft)
Limiting Internal Dimensions 208 x 305 x 147 cm, (82 x 119 x 60 in)
Maximum Gross Weight 4626 kg (10200 lb)
Tare Weight 400 kg (880 lb)

Sea Freight

Inside length Inside width Inside height Door width Door height Capacity Tare height Maxi cargo
Standard 20' General Purpose (GP)
5.90m 2.35m 2.39m 2.34m 2.28m 33.2Cu.m 2,230Kgs 21,770Kgs
Standard 40' General Purpose (GP)
12.03m 2.35m 2.39m 2.34m 2.28m 67.7Cu.m 3,700Kgs 26,780Kgs
Inside length Inside width Inside height Door width Door height Capacity Tare height Maxi cargo
20' Reefer
5.42m 2.27m 2.26m 2.25m 2.21m 28.3Cu.m 3,200Kgs 20,800Kgs
40' Reefer
11.49m 2.27m 2.19m 2.28m 2.15m 57.8Cu.m 4,900Kgs 25,580Kgs
40' Reefer (High Cube)
11.55m 2.29m 2.50m 2.29m 2.44m 66.6Cu.m 4,500Kgs 25,980Kgs
Inside length Inside width Inside height Door width Door height Capacity Tare height Maxi cargo
20' Open Top
5.89m 2.31m 2.35m 2.28m 2.18m 32.23Cu.m 2,400Kgs 21,600Kgs
40' Open Top
12.02m 2.35m 2.34m 2.34m 2.27m 65.5Cu.m 3,850Kgs 26,630Kgs
Inside length Inside width Inside height Door width Door height Capacity Tare height Maxi cargo
20' Flat Rack
5.62m 2.20m 2.23m - - - 2,530Kgs 21,600Kgs
40' Flat Rack
12.08m 2.43m 2.10m - - - 5,480Kgs 39,000Kgs
20' Flat Rack collapsible
5.61m 2.2m 2.23m - - - 2,750Kgs 27,730Kgs
40' Flat Rack collapsible (Stak Bed)
12.08m 2.12m 2.0m - - - 5,800Kgs 39,000Kgs
Inside length Inside width Inside height Door width Door height Capacity Tare height Maxi cargo
Standard 20' General Purpose (GP)
5.90m 2.35m 2.39m 2.34m 2.28m 33.2Cu.m 2,230Kgs 21,770Kgs
20' Platform
6.05m 2.43m 2.23m - - - 2,750Kgs 24,000Kgs
40' Platform
12.18m 2.40m 1.95m - - - 5,800Kgs 39,000Kgs
